Conformal coating · dispensing · curing
Complete coating and dispensing lines, built around your board.
13
Machine models
±0.02
mm repeatability
7×24
Technical support
CE · CCC · UL
Compliance
Selective coating machines, dispensing machines, board handling and IR, UV and vertical curing ovens - specified, integrated and commissioned as one line.
Selective coating
±0.02 mm repeatability, ±1 mm spray edge.
13
Machine models
±0.02
mm repeatability
7×24
Technical support
CE · CCC · UL
Compliance
Dual and quad valve gantries on imported servo and ball-screw modules. New program in under ten minutes, changeover in under two.
Curing
IR, UV and vertical curing, sized to the cure schedule.
13
Machine models
±0.02
mm repeatability
7×24
Technical support
CE · CCC · UL
Compliance
Inline ovens for short cures; vertical storage ovens holding up to 64 layers where cure time would otherwise stall the line.
Line video
A coating line running at takt.
Loader, selective coating, curing and unload - the full sequence in one uninterrupted take.
Equipment
Four families. One supplier.
Representative models shown. The full range - thirteen machines with datasheets, materials lists and dimensional drawings - sits behind each family.
T series
Conformal coating machines
Selective spraying of three-proof paint with atomizing and precision valves. Programs edit as trajectories, then mirror, array and copy for multi-panel boards.
T650 — 4 valvesT550U — U axis
D series
Dispensing machines
Programmable dispensing for fixing, bonding, underfill and potting. Valve, supply system and working area configured from your material and board.
D600D1200
IR · UV · V series
Curing ovens
IR tunnels at ±5 °C, 365 nm UVA units, and vertical storage ovens at ±1 °C - matched to the cure schedule your material needs.
IR4U2V600
Handling
Board handling equipment
Loaders, unloaders, inspection conveyors and buffers at 900 mm transport height, SMEMA linked so the line runs without manual transfer.
LoadersConveyors
Lines
Two lines, station by station.
Every station is I.C.T equipment on one SMEMA-linked conveyor at 900 mm transport height, so boards run from loader to inspection without manual handling.
01
Selective conformal coating line
03
Board Conveyor
Aluminium alloy track with stainless steel chain, 2–13 m/min.
Board handling equipment02
Dispensing line
03
Board Conveyor
Aluminium alloy track with stainless steel chain, 2–13 m/min.
Board handling equipment05
AOI inspection
Automated optical inspection of dispensing position and volume.
AOI inspection systemProcesses
Coating, dispensing, curing.
Conformal coating
Three-proof paint applied selectively, with atomizing and precision valves changed as modules for different products.
PCB size50×50 – 450×460 mmCoating width2 – 30 mmEdge definition±1 mm
Dispensing
Adhesives, UV glue, ink, lubricant, catalyst, solvent and protective agents for fixing, bonding and potting.
Viscosity range50 – 1500 CPSModelsD400 · D600 · D1200Valve changeModular
Curing
IR, UV and vertical curing, chosen by cure time and thermal budget rather than by whatever is already on the floor.
IR accuracy±5 °CVertical accuracy±1 °CCure time5 – 10000 min
Customer cases
Lines in production.
Selected coating and dispensing projects from installed customer lines and delivery work.
Customer line - Belarus
Conformal coating and UV curing in production
A customer-side coating and curing line arranged for controlled application, inspection and stable production.
Line - Coating and curing - Result - Installed production line
Customer delivery - Malaysia
Dispensing equipment delivered for production handover
A dispensing line delivery with customer-side support and equipment handover for production use.
Line - Dispensing - Result - Delivered and handed over
Trusted by manufacturers in 60+ countries
What customers say
In their words.
Service & delivery
From the first line layout to the third year of production.
01
Pre-consultation
Line layout, process review and equipment selection for the full line before an order is placed.
02
Factory warranty
One-year warranty on factory service.
03
Installation
On-site installation and commissioning to bring the line into stable production.
04
Technical training
Operator to maintenance training, Level 1 through Level 3.
Inquiry
Tell us the board. We will quote the line.
The more you tell us about board size, material and throughput, the closer the first proposal will be.
Email
smt@smt11.com
Tel / WhatsApp
+86 138 2745 8718
Factory
I.C.T Industrial Park, Building 1, No.17 Dalong Road, Shigu Town, Nancheng Street, Dongguan, Guangdong, China
smt@smt11.com
Tel / WhatsApp
+86 138 2745 8718
Factory
I.C.T Industrial Park, Building 1, No.17 Dalong Road, Shigu Town, Nancheng Street, Dongguan, Guangdong, China
Request a quote
Share the process and board information available to you. The sales and engineering team can then review the equipment or line route that fits the project.
